Description
Available and shipping now!
The Thrifty 10 Pin Magnetic Encoder was designed to provide teams a minimum configuration option for absolute position sensing. Simply plug the included 10 pin ribbon cable into your Nova or Spark Max and read the included magnet's absolute position with 12 bit precision.
Key features for reliability include:
- Improved transient protection
- Red/yellow/green LED to indicate magnet position and power
- Keyed connection to prevent flipping the connection the wrong way
- Plugs directly into Nova and Spark Max, no adapter needed
Kit Contents:
- 1 case that mounts directly onto standard 3-48 encoder pattern
- Mounting hardware - 1/2" Long 3-48 Screws for CTRE Case
- 1x 0.25” x 0.50” diametrically polarized magnet
- 1x Encoder board
- 1x 12” 10 Pin Ribbon Cable
OnShape and electrical documentation can be found below.
- PDF Viewer
-
